Core Technical Specifications of the ABB SPGU240A1 SPGU 240 A1
The ABB SPGU240A1 SPGU 240 A1 works as a power supply card for industrial control systems. This card converts input voltage into stable regulated output for connected modules. Engineers select it for dependable power delivery inside compatible ABB platforms.
Physical Dimensions and Weight Parameters
The SPGU240A1 SPGU 240 A1 uses a compact card layout that fits standard ABB racks. Its moderate weight allows one technician to handle installation safely. Additionally, the slim profile preserves airflow inside crowded cabinets.
| Parameter | Specification |
|---|---|
| Product Type | Power Supply Card |
| Compatibility | ABB Control Systems |
| Mounting Style | Rack or Panel Mount |
| Interface Type | Multi-pin Connector |
| Input Voltage | Standard Industrial Supply Range |
| Output Type | Regulated DC Output |
| Circuit Type | Power Conversion Stages |
| Storage Element | Onboard Capacitor Bank |
| Operating Role | Voltage Regulation and Power Delivery |
Interface and Connection Details
Multi-pin connectors on the link the card to backplane and field wiring. These interfaces carry supply voltage, status data, and fault feedback. Consequently, technicians trace power faults quickly through standard ABB diagnostics.
Component Count and Internal Layout
The card contains conversion stages, regulation circuits, and signal isolation blocks. Each component supports stable power delivery across the full load range. Moreover, the modular layout simplifies inspection and card-level replacement.
Energy Storage and Power Characteristics
A capacitor bank on the SPGU240A1 SPGU 240 A1 stabilizes voltage during load switching transients. This energy storage element maintains output integrity when supply rails fluctuate. Therefore, the card delivers consistent power even in noisy plants.
Integration and Maintenance Notes
The drops into existing ABB cabinets without extra adapters. Replacement work requires proper grounding to prevent electrostatic damage. Meanwhile, routine checks keep the card within specified performance limits.
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 90 × 45 × 100 mm |
