The ABB SCC-F 23212-0-110310 regulates sample gas flow before it reaches analyzers in continuous emission monitoring systems. Engineers specify this unit when stable flow delivery must protect sensitive measurement cells. Consequently, the module maintains consistent sample pressure across varying process conditions.
Physical Dimensions and Weight Data
Analyzer shelters often limit how technicians arrange gas conditioning hardware along the sample train. Therefore, this unit keeps a compact profile while supporting high sample flow rates. It weighs roughly 4.5 kg and measures 250 mm in height. Additionally, its width spans 180 mm with a depth of 150 mm.
Interfaces and Connectivity Features
Reliable gas delivery depends on secure connections at every sample inlet and outlet. The unit provides PTFE-lined ports that resist corrosive gases. Furthermore, front-panel indicators let technicians verify flow status instantly. The housing supports wall mounting without additional brackets.
Component Count and Construction Details
Internal construction shapes both flow stability and long-term reliability. This unit carries more than 40 discrete components across its regulation circuit. Moreover, the diaphragm pump uses corrosion-resistant materials for aggressive samples. The housing material meets flame-retardant standards for industrial shelters.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Gas feed unit |
| Dimensions | 250 × 180 × 150 mm |
| Weight | 4.5 kg |
| Mounting | Wall or panel |
| Sample Ports | PTFE-lined |
| Flow Rate | Up to 200 l/h |
| Outlet Pressure | 0.5–2 bar |
| Component Count | 40+ discrete parts |
| Operating Temperature | 5°C to 45°C |
| Power Supply | 230 VAC |
| Isolation Voltage | 1500 VAC |
| Housing Material | Flame-retardant |
Flow Performance and Compliance
Stable sample flow directly influences overall analyzer measurement accuracy. The unit maintains flow within ±2% across the full pressure range. Meanwhile, the diaphragm pump resists corrosion from acidic sample gases. These features support dependable operation in harsh emission monitoring environments.
Industrial sites also demand strict safety certifications before deployment. The unit complies with IEC and UL standards for industrial gas conditioning equipment. In addition, it meets CE requirements for electromagnetic compatibility. These credentials support dependable operation in continuous emission monitoring systems.
