The ABB SCC-C 23070-0-10121210 cools sample gas before it enters analyzers in continuous emission monitoring systems. Engineers specify this unit when moisture removal must protect sensitive measurement cells. Consequently, the cooler delivers stable outlet dew points across varying process loads.
Physical Dimensions and Weight Data
Cabinet space often limits how technicians arrange gas conditioning hardware inside analyzer shelters. Therefore, this cooler keeps a compact profile while supporting high sample flow rates. It weighs roughly 12 kg and measures 400 mm in height. Additionally, its width spans 300 mm with a depth of 250 mm.
Interfaces and Connectivity Features
Reliable gas conditioning depends on secure connections at every sample inlet and outlet. The unit provides PTFE-lined sample ports that resist corrosive gases. Furthermore, front-panel indicators let technicians verify cooler status instantly. The housing supports wall mounting without additional brackets.
Component Count and Construction Details
Internal construction shapes both cooling efficiency and long-term reliability. This cooler carries more than 60 discrete components across its refrigeration circuit. Moreover, the heat exchanger uses corrosion-resistant materials for aggressive samples. The housing material meets flame-retardant standards for industrial shelters.
Key Technical Specifications
| Parameter | Specification |
|---|---|
| Module Type | Sample gas cooler |
| Dimensions | 400 × 300 × 250 mm |
| Weight | 12 kg |
| Mounting | Wall or panel |
| Sample Ports | PTFE-lined |
| Cooling Capacity | 200 kJ/h |
| Outlet Dew Point | 2°C to 5°C |
| Sample Flow Rate | Up to 300 l/h |
| Component Count | 60+ discrete parts |
| Operating Temperature | 5°C to 45°C |
| Power Supply | 230 VAC |
| Isolation Voltage | 1500 VAC |
| Housing Material | Flame-retardant |
Cooling Performance and Compliance
Stable outlet dew point directly influences overall analyzer measurement accuracy. The cooler maintains dew point within ±0.5°C across the full flow range. Meanwhile, the refrigeration circuit resists corrosion from acidic sample gases. These features support dependable operation in harsh emission monitoring environments.
Industrial sites also demand strict safety certifications before deployment. The unit complies with IEC and UL standards for industrial gas conditioning equipment. In addition, it meets CE requirements for electromagnetic compatibility. These credentials support dependable operation in continuous emission monitoring systems.
