High-Performance Power for AC 800M Systems
This power module provides reliable 24 V DC power for ABB AC 800M and S800 I/O systems. The SA801F delivers 10 A of continuous current for demanding industrial control applications. It includes comprehensive protection features such as overvoltage, overcurrent, and overtemperature shutdown. Moreover, the module offers status indicators for real-time monitoring of output and fault conditions. Its robust design supports operation in harsh environments with wide temperature variations.
Technical Specifications and Physical Attributes
The SA801F accepts an input voltage range of 20 to 30 V DC. It outputs a regulated 24 V DC with a maximum current of 10 A. The module incorporates an active PFC circuit for improved power factor and efficiency. It measures 300 mm in depth, 200 mm in height, and 80 mm in width . The unit weighs approximately 2.5 kg . Furthermore, the SA801F operates reliably across a temperature range of -25 °C to +70 °C . It also supports parallel operation for redundancy or increased power capacity.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Part Number | SA801F (3BDH000011R1) |
| Compatibility | AC 800M, S800 I/O |
| Input Voltage | 20–30 V DC |
| Output Voltage | 24 V DC |
| Output Current | 10 A |
| Protection | Overvoltage, overcurrent, overtemperature |
| Parallel Operation | Yes |
| Dimensions (W x H x D) | 80 mm x 200 mm x 300 mm |
| Weight | Approx. 2.5 kg (5.5 lb) |
| Operating Temp. | -25 °C to +70 °C |
| Mounting | DIN Rail |
Installation and System Integration
This module powers controllers, I/O modules, and field devices in large automation systems. First, mount the SA801F securely onto a DIN rail within the control cabinet. Then, connect the DC input source to the designated terminals using properly sized cables. For the output, wire the 24 V terminals to the backplane or distribution bus. When using two modules in parallel, employ the recommended load-sharing configuration. The SA801F meets all relevant industrial standards for safety and electromagnetic compatibility.
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 234 × 99 × 216 mm |
