Reliable System Power for Advant Controllers
This power supply module delivers stable DC power for ABB Advant Controller systems. The SA610 converts AC or DC input into a regulated 24 V DC output. It supplies 60 W of continuous power for controllers, I/O modules, and communication interfaces. Moreover, the module features built-in protection against overcurrent and short-circuit faults. Its compact, robust design suits DIN rail mounting within industrial cabinets.
Technical Specifications and Physical Attributes
The SA610 accepts a wide range of AC and DC input voltages for global compatibility. It supports 110/120/220/240 V AC and 110/220/250 V DC inputs . The module outputs 24 V DC at 2.5 A, delivering 60 W of power . Its dimensions measure 252 mm in depth, 273 mm in height, and 40 mm in width . The unit weighs approximately 1.7 kg . Furthermore, the SA610 operates reliably across a temperature range of -25 °C to +70 °C .
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Part Number | SA610 (3BHT300019R1) |
| Compatibility | Advant Controller 110/160 |
| AC Input | 110/120/220/240 V AC |
| DC Input | 110/220/250 V DC |
| Output Voltage | 24 V DC |
| Output Power | 60 W |
| Dimensions (W x H x D) | 40 mm x 273 mm x 252 mm |
| Weight | Approx. 1.7 kg (3.75 lb) |
| Operating Temp. | -25 °C to +70 °C |
| Protection | Overcurrent, short-circuit |
| Origin | Sweden |
Installation and System Integration
This module serves as the primary power source for Advant Controller 110 and 160 systems. First, mount the SA610 securely onto a DIN rail inside the control cabinet. Then, connect the AC or DC input lines to the designated terminals according to the label. For the DC output, wire the 24 V terminals to the backplane or distribution bus. Always use appropriate cable gauges for the input and output currents. The SA610 complies with RoHS and WEEE environmental standards for sustainable operation .
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 234 × 99 × 216 mm |
