Product Overview
The ABB PM151 3BSE003642R1 operates as a central processor module for the ABB Advant Master and AC 400 series control systems . This module executes real-time control logic and handles system communication tasks with high efficiency . Therefore, the PM151 serves as a reliable replacement for similar CPU modules in legacy ABB installations .
Technical Specifications
The PM151 comes equipped with a powerful Motorola MC68020 processor and features 8 MByte of SIMM memory for application handling . Additionally, this module stores its system software on a removable flash memory card for easy updates . The unit draws its operating power from the system backplane and requires no external battery supply .
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Order Number | PM151 3BSE003642R1 |
| Product Type | Processor Module / CPU |
| Compatible Systems | Advant Master, AC 400 Series |
| Processor | Motorola MC68020 |
| Memory Capacity | 8 MByte SIMM |
| Flash Memory Slot | 1 (for system software) |
| Submodule Slots | 4 (two with MB300 interface) |
| Communication Ports | RS-232-C |
| Dimensions (W x H x D) | 234 x 99 x 216 mm |
| Net Weight | 2.85 kg |
| Operating Temperature | 0°C to +55°C |
| Origin | Sweden |
Key Design Features
The PM151 3BSE003642R1 incorporates ECC error correction for its dynamic read/write memory, ensuring data integrity during critical operations . Since the module lacks internal batteries, it relies entirely on the host chassis for power delivery . Furthermore, the unit features RS-232-C ports for connecting to Advant Station 100 workstations, printers, and MasterView 320 operator panels . Its rugged mechanical design guarantees stable performance across a wide temperature range .
Application and Integration
The PM151 3BSE003642R1 finds extensive use in power generation, chemical processing, and manufacturing automation . Maintenance personnel often deploy it as a spare CPU for Advant Master systems, loading existing DUAP applications after a cold start . Consequently, this module provides a dependable solution for sustaining legacy ABB control infrastructures .
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 234 × 99 × 216 mm |
