Product Overview
The ABB PM150V08 functions as a central processor module for the ABB Advant Master process control system . This high-performance unit executes real-time control logic, system scheduling, and data management across the sub-rack backplane . Accordingly, the PM150V08 integrates seamlessly into Advant Controller 410 and AC 400 series systems .
Technical Specifications
The PM150V08 features a Motorola MC68020 processor and comes equipped with 8 MByte SIMM memory . For long-term data retention, this module stores application programs in DUAP format on a flash memory card . Furthermore, the module operates on 24 V DC power drawn directly from the system backplane .
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Order Number | 3BSE009598R1 |
| Product Type | Processor Module / CPU |
| Compatible Systems | Advant Master, AC 410, AC 400 Series |
| Processor | Motorola MC68020 |
| Memory Capacity | 8 MByte SIMM (expandable) |
| Communication Ports | RS-232-C (for Advant Station 100, printers) |
| Submodule Slots | 4 (two with MB300 interface) |
| Flash Memory Slot | 1 (for system software) |
| Dimensions (W x H x D) | 234 x 99 x 216 mm |
| Net Weight | 2.85 kg |
| Operating Temperature | 0°C to +55°C |
| Origin | Sweden |
Key Design Features
The PM150V08 incorporates ECC error correction circuitry on its dynamic read/write memory, which automatically detects and corrects data errors for enhanced reliability . Notably, this module requires no internal battery, relying instead on the host chassis for power distribution . Moreover, the module features dedicated RS-232-C ports for connecting to Advant Station 100 engineering workstations, printers, and MasterView 320 operator interfaces . Its rugged construction ensures stable performance in demanding industrial environments .
Application and Integration
The PM150V08 serves as the main CPU in ABB Advant Master and AC 400 series DCS installations. Maintenance teams frequently deploy it as a direct spare for failed PM150 units, loading the same DUAP applications after a cold start . Consequently, industries such as power generation, chemical processing, and manufacturing rely on this module for critical control tasks .
Details
| Weight | 2.85 kg |
|---|---|
| Dimensions | 234 × 99 × 216 mm |
