Technical Specifications Overview

The table below details the core technical parameters of this termination unit.

Dedicated 4-20 mA Current Loop Interface

The NTCL01-A termination unit provides a dedicated interface for 4-20 mA current loop signals from 2-wire transmitters. This termination unit supplies regulated 24 VDC power to each connected transmitter, eliminating the need for separate external power supplies. The 16-channel design supports high-density installations, reducing the overall footprint in control cabinets.

The unit provides a regulated 24 VDC supply per channel, delivering up to 25 mA of current to each transmitter. This regulated power ensures consistent transmitter operation despite fluctuations in the main supply voltage. The maximum loop resistance of 750 Ω accommodates most standard 4-20 mA transmitters and allows for reasonably long cable runs without signal degradation.

Precision Signal Conditioning and Accuracy

This termination unit incorporates precision current sensing resistors that convert the 4-20 mA loop current into a voltage signal for the analog input module. The unit maintains high accuracy across the full 4-20 mA range, ensuring reliable measurement of pressure, temperature, flow, and level variables. The design minimizes thermal drift, preserving measurement accuracy over the entire operating temperature range.

Each channel includes reverse polarity protection, preventing damage to the unit or connected transmitters from incorrect wiring. The NTCL01-A also features transient suppression circuitry that protects against voltage spikes from inductive loads or lightning strikes.

Physical Design and Installation Features

This termination unit measures 67 mm in width, 130 mm in height, and 120 mm in depth, with a weight of 0.38 kg. The compact form factor accommodates high-density installations within standard control panels. Users can mount the NTCL01-A either on a DIN rail or directly onto the backplane, offering excellent flexibility for various panel layouts.

The 34-point removable screw terminal block supports wires up to 2.5 mm² (AWG 14), ensuring reliable connections for both signal and power wiring. A 34-pin flat ribbon cable links the termination unit directly to the corresponding analog input module, creating a clean and organized system architecture.

System Integration and Application Benefits

This termination unit eliminates the need for external power supplies and signal conditioners, simplifying system design and reducing component count. The NTCL01-A provides a standardized solution for 4-20 mA transmitter connections across multiple projects, improving consistency and reducing engineering effort. It operates reliably across a temperature range of 0°C to 60°C, withstanding humidity from 5% to 95% (non-condensing).
