The ABB 07DI92 is a high-performance Digital I/O module from the AC31 series, designed for industrial automation systems. It provides 32 digital inputs at 24 V DC, ideal for reliable and fast digital signal monitoring.
Key Features
- 32 Digital Inputs: 24 V DC, divided into 4 electrically isolated groups
- System Bus Integration: Uses two digital addresses on the CS31 bus
- Electrically Isolated Bus: Protects communication from the module circuitry
- Status Indicators: 32 green LEDs for inputs, 3 red LEDs for errors
- Manual Testing: Test button for functional verification
- Mounting Flexibility: DIN rail or 4 screws
Technical Specifications
| Feature | Specification |
|---|---|
| Model | 07DI92 |
| Product ID | GJR5252400R0101 |
| Catalog | AC31 |
| Country of Origin | Germany (DE), Spain (ES) |
| HS Code | 85389091 |
| Dimensions | 16 cm × 16 cm × 12 cm |
| Weight | 0.8 kg |
| Supply Voltage | 24 V DC |
| Digital Inputs | 32 channels, 4 isolated groups |
| CS31 Bus Address | 2 digital addresses for inputs |
| LEDs | 32 green for input status, 3 red for errors |
| Test Button | Yes |
| Mounting | DIN rail (15 mm) or 4 screws |
| Operating Temperature | 0°C to 55°C |
Applications
- Industrial Automation: Fast and reliable digital signal monitoring
- Process Control Systems: Integration with AC31 series controllers
- Machine Automation: Connects sensors and actuators to central units
- Distributed Control Systems: Easy CS31 bus integration
Ordering Information
- Product ID: GJR5252400R0101
- Minimum Order: 1 piece
- Origin: Germany / Spain
Details
| Weight | 0.8 kg |
|---|
