The ABB DSTX170 functions as a centralized interface between field devices and control networks. This connection unit streamlines wiring for sensors, actuators, and automation controllers. It replaces scattered point-to-point cabling with an organized, modular layout.

Technical Specifications

Physical Dimensions and Mounting Capabilities

This unit measures 170 millimeters in height with an 85-millimeter width profile. It weighs 0.45 kilograms, providing a sturdy yet manageable form factor. The housing utilizes flame-retardant thermoplastic that resists impact and chemical exposure. Technicians can mount this DSTX170 onto standard 35-millimeter DIN rails effortlessly. Consequently, the unit integrates seamlessly into existing control cabinet configurations.

Interface Configuration and Connectivity

The DSTX170 provides 32 individual I/O channels through removable screw terminal blocks. Each terminal block accepts wire gauges from 0.2 to 2.5 square millimeters. This versatile range accommodates both field wiring and internal control connections. Moreover, the removable design enables technicians to pre-wire the unit offline. This approach cuts installation time substantially and reduces system downtime.

Signal Routing and Channel Organization

This connection unit consolidates signal routing for numerous field devices into one location. It distributes power and data signals across its 32 channels with efficiency. Each channel features clearly labeled terminal positions to prevent wiring errors. Additionally, the unit incorporates internal bus bars for streamlined power sharing. This design eliminates the need for external power distribution components.

Construction Quality and Environmental Resilience

ABB builds this connection unit to perform reliably in demanding industrial environments. The housing effectively resists dust, moisture, and common chemical agents. It operates without failure across a temperature range from -20°C to +60°C. Furthermore, this unit contains no internal batteries or energy storage components. This design removes maintenance concerns related to charge retention or replacement schedules.
