This multifunctional temperature input module handles precise signal acquisition from thermal sensors. It belongs to the ABB Freelance series, a product line designed for process control applications. The DSTX170 57160001-ADK accepts various thermocouple and RTD inputs with high accuracy.

Technical Specifications

Engineers will appreciate the module’s versatile configuration for different sensor types. It supports multiple thermocouple types including J, K, T, and S. Additionally, the unit accommodates PT100 and PT1000 RTD sensors for resistance-based temperature measurement.

Design and Configuration

This module features eight independent input channels for flexible sensor connection. Each channel offers programmable filtering to reduce electrical noise interference. Moreover, the DSTX170 57160001-ADK provides linearization and cold junction compensation for thermocouple inputs.

Technicians can configure each channel individually for specific sensor types and ranges. The module stores calibration data locally for consistent performance across power cycles. Furthermore, LED indicators display channel status and diagnostic information.

Application and Compatibility

The DSTX170 57160001-ADK integrates seamlessly into ABB Freelance 2000 and 800F control systems. It mounts directly on the process station backplane for centralized temperature monitoring. Users often deploy this module in applications requiring precise thermal management.

ABB continues to support the Freelance platform with comprehensive automation solutions. This temperature input module ensures reliable signal acquisition for demanding process environments.
