The DSQC609 3HAC14178-1 from ABB functions as a reliable power supply module for industrial robot controller systems. This unit converts incoming AC mains voltage into regulated DC power for robot electronics and control circuits. Its compact, efficient design minimizes heat generation while delivering stable output under varying load conditions. Therefore, robotic systems maintain consistent performance even during extended production cycles and demanding multi-axis movements.
Weighing approximately 2.65 lbs (1.20 kg), the DSQC609 3HAC14178-1 features a rugged metal enclosure suitable for direct mounting within ABB robot controller cabinets. The module accepts wide-range AC input from 200 to 500 VAC, accommodating global installations across different regional power standards. It provides regulated 24 VDC output for control electronics, I/O modules, communication interfaces, and field devices. Additionally, the unit incorporates comprehensive protection features including overcurrent, overvoltage, and thermal shutdown mechanisms.
Efficient Power Conversion and Distribution
The DSQC609 3HAC14178-1 delivers clean, regulated 24 VDC power to multiple robot system components through protected output circuits. Its high-efficiency design significantly reduces power loss and minimizes cooling requirements within the controller enclosure. The module includes robust input filtering to attenuate electrical noise from the AC mains before reaching sensitive electronics. This integrated filtering ensures stable DC output even in electrically noisy industrial environments with heavy machinery.
Comprehensive Protection and Monitoring Features
This power supply module incorporates built-in soft-start circuitry that prevents excessive inrush current during initial power-up sequences. Automatic current limiting protects both the power supply and connected equipment from overload conditions without requiring replacement fuses. LED indicators provide immediate visual confirmation of input power presence, output voltage status, and fault conditions during normal operation. These diagnostic features enable maintenance personnel to quickly verify power system integrity without external test equipment.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | ABB |
| Product Type | Power Supply Module |
| Product Line | DSQC Series |
| Part Number | DSQC609 3HAC14178-1 |
| Weight | 2.65 lbs (1.20 kg) approximately |
| Input Voltage | 200-500 VAC (wide-range) |
| Output Voltage | 24 VDC regulated |
| Output Power | Sufficient for control electronics and I/O |
| Protection Features | Overcurrent, Overvoltage, Thermal shutdown |
| Input Filtering | Built-in EMI/RFI filtering |
| Soft-Start Circuitry | Yes |
| Current Limiting | Automatic reset |
| Mounting Type | Cabinet mounting |
| Diagnostic Indicators | LED status indicators |
| Cooling Method | Natural convection |
| Operating Temperature | 0°C to 55°C |
| Application | ABB industrial robot controllers |
Details
| Dimensions | 110 × 55 × 90 mm |
|---|
