The DSQC608 from ABB serves as a dedicated customer I/O power supply module for industrial robot systems. This unit provides isolated power specifically for field devices connected to robot I/O interfaces. Its design ensures clean, regulated voltage for sensors, actuators, and other customer-supplied equipment. Therefore, external devices operate reliably without introducing electrical noise into the robot control system.
Weighing approximately 2.20 lbs (1.00 kg), the DSQC608 features a compact enclosure suitable for direct mounting within ABB robot controller cabinets. The module accepts input voltage from the main robot power supply and converts it to isolated 24 VDC for customer I/O circuits. It provides multiple output channels with individual current limiting to protect both the module and connected field devices. Additionally, the unit incorporates short-circuit protection on each output to prevent faults from propagating through the I/O system.
Comprehensive I/O Power Distribution
The DSQC608 delivers regulated 24 VDC power to customer-supplied sensors, pushbuttons, indicators, and actuator interfaces. Its multiple output channels allow segregation of different device types, simplifying troubleshooting during system maintenance. Each channel includes electronic current limiting that automatically resets after fault conditions clear. This smart protection eliminates the need for replaceable fuses while ensuring continuous operation of unaffected channels during partial system faults.
Advanced Isolation and Diagnostic Features
This power supply module incorporates galvanic isolation between the robot control circuits and customer I/O power, preventing ground loops and noise transmission. Built-in monitoring circuits continuously check output voltage levels and channel current draw against normal operating parameters. LED indicators provide immediate visual confirmation of input power status, channel activity, and fault conditions during normal robot operation. These diagnostic features enable maintenance personnel to quickly identify I/O power issues without external test equipment.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | ABB |
| Product Type | Customer I/O Power Supply |
| Product Line | DSQC Series |
| Part Number | DSQC608 |
| Weight | 2.20 lbs (1.00 kg) approximately |
| Input Source | Main robot power supply |
| Output Voltage | 24 VDC isolated |
| Output Channels | Multiple with individual protection |
| Protection Features | Short-circuit protection, Current limiting |
| Isolation Type | Galvanic isolation |
| Fault Recovery | Automatic reset after fault clearance |
| Mounting Type | Cabinet mounting |
| Diagnostic Indicators | LED status indicators per channel |
| Application | Customer I/O devices for ABB robots |
| Operating Temperature | Industrial range |
Details
| Weight | 0.91 kg |
|---|---|
| Dimensions | 110 × 55 × 90 mm |
