The ABB DSQC236G functions as a high-performance drive unit within ABB Robotics control systems. This module provides precise power amplification and control for robot axis motors. Consequently, it ensures smooth, accurate motion for demanding industrial automation applications.

Core Technical Specifications

We engineered the ABB DSQC236G for reliable and efficient motor control in continuous-duty robotic operations. The table below details its essential physical and electronic parameters:

Precision Motor Power Amplification

The DSQC236G takes low-power command signals from the robot controller and amplifies them to drive axis motors. It delivers precisely controlled current and voltage to achieve desired speeds and torques. Therefore, it translates digital commands into smooth, accurate physical motion.

Seamless Integration with ABB Controllers

You install this drive unit directly into the dedicated drive rack within an ABB robot controller cabinet. It connects to the backplane, receiving power and control signals from the main computer. Consequently, it becomes an integral part of the coordinated ABB Robotics control system.

Robust Design for Continuous Operation

ABB engineered this drive unit for long-term reliability in demanding 24/7 industrial environments. Its robust construction and efficient cooling ensure stable performance even under heavy loads. Hence, you can depend on the DSQC236G for years of uninterrupted service.

Efficient Heat Dissipation

Integrated heat sinks and optional forced-air cooling maintain safe operating temperatures during continuous use. This thermal management prevents overheating, ensuring consistent performance and extended component life. As a result, the drive unit maintains precision even in high-duty-cycle applications.

Multiple Axis Control Capability

Depending on the specific robot configuration, the DSQC236G may control one or multiple robot axes. It works in concert with other drive units in the rack to coordinate all robot movements. Therefore, it contributes to the synchronized motion required for complex paths.

Comprehensive Protection Features

Built-in protection circuits safeguard the drive unit and connected motors from overcurrent, overvoltage, and overtemperature conditions. These features prevent damage during fault events and enhance overall system reliability. Consequently, you reduce downtime and maintenance costs.

Genuine ABB Quality and Performance

As an original ABB component, the DSQC236G meets the strict quality standards of the manufacturer. It undergoes rigorous testing to ensure compatibility and performance in ABB Robotics systems. As a result, you receive a product that performs exactly as the original equipment.

Essential for Robot Motion Control

The drive unit plays a critical role in the robot’s motion control loop, directly affecting performance. Its precision and responsiveness determine how accurately the robot follows programmed paths. Hence, the DSQC236G is essential for applications requiring high accuracy and repeatability.
