Introduction to DSDP150 5716-0001-GF Pulse Distribution Board
The DSDP150 5716-0001-GF Pulse Distribution Board by ABB is a highly efficient and versatile component in industrial automation systems. Designed for precision and reliability, this unit plays a crucial role in pulse distribution, ensuring optimal performance across multiple connected devices. Its robust construction, advanced features, and impressive technical specifications make it suitable for demanding applications in various industries.
Key Features of DSDP150 5716-0001-GF Pulse Distribution Board
- Manufacturer: ABB
- Category: Pulse Distribution Board
- Purpose: To provide reliable distribution of pulse signals to multiple components.
This model guarantees superior functionality and performance, ensuring smooth operation even under heavy-duty conditions. With precise engineering, it meets the highest standards of industrial automation and control systems.
Technical Specifications
| Parameter | Specification |
|---|---|
| Dimensions (L x W x H) | 150mm x 200mm x 90mm |
| Weight | 1.2 kg |
| Input Voltage | 24V DC |
| Pulse Distribution | Up to 10 pulse outputs |
| Current Rating | 10A per channel |
| Energy Storage | Capacitor-based energy storage |
| Interface | DIN Rail mount |
| Operating Temperature | -10°C to 60°C |
| Relative Humidity | 5% to 95% (non-condensing) |
| Protection Class | IP20 |
| Mounting Type | Rack-mountable |
Why Choose DSDP150 5716-0001-GF Pulse Distribution Board?
The offers robust performance and high accuracy. Its energy-efficient design allows it to handle heavy loads without compromising on efficiency. The unit’s compact size makes it ideal for installations with space constraints. Additionally, its wide operational temperature range ensures it can perform reliably in various environmental conditions.
Its DIN rail mounting system simplifies installation and ensures secure placement in industrial setups. The is widely used in industrial applications such as automation control, signal distribution, and system integration.
Compatibility and Integration
The DSDP150 5716-0001-GF is compatible with a range of ABB control systems and automation devices. It integrates seamlessly with various industrial environments, contributing to increased system reliability and efficiency. The unit is engineered for long-lasting durability, ensuring minimal maintenance needs.
Summary of Key Specifications
- Model: DSDP150 5716-0001-GF
- Input Voltage: 24V DC
- Current Rating: 10A
- Pulse Outputs: 10 channels
- Mounting: DIN Rail
- Dimensions: 150mm x 200mm x 90mm
- Weight: 1.2 kg
The DSDP150 5716-0001-GF is a trusted choice for industrial automation systems where precision, durability, and reliability are essential.
Details
| Weight | 0.595 kg |
|---|---|
| Dimensions | 18 × 225 × 209.7 mm |
