Core Function and Integration Role
The ABB DSCS131 57310001-LM serves as a specialized communication interface module. Consequently, it provides a vital data link within distributed control architectures. This module excels at managing high-speed data exchange between system levels. Therefore, it enhances overall network responsiveness and control precision.
Performance and System Compatibility
Specifically designed for robust performance, the module supports deterministic data transfer. Furthermore, it seamlessly integrates with ABB’s Symphony DCS and Advant OCS family of controllers. This compatibility ensures reliable operation in critical process automation environments. Ultimately, it acts as a cornerstone for scalable and efficient plant-wide communication.
Detailed Technical Specifications
Engineered for industrial durability, the module features a compact, rack-mountable design. The following table details its comprehensive technical and physical parameters.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | DSCS131 57310001-LM |
| Product Type | Communication Interface Module |
| Compatible System Series | Harmony/Advant Controller Family, Symphony DCS |
| Primary Function | High-speed bus communication & protocol handling |
| Bus Communication Standard | Proprietary ABB high-speed control network |
| Power Supply Requirement | 24 VDC (typically via system backplane) |
| Dimensions (H x W x D) | Approx. 30 mm x 200 mm x 160 mm (standard 6U form factor) |
| Net Weight | Approximately 0.7 kg |
| Operating Temperature Range | 0°C to +60°C (32°F to 140°F) |
| Storage Temperature Range | -40°C to +85°C |
| Protection Rating | IP20 for installation in protected control cabinets |
| Primary Interface/Connector | High-density system bus connector & terminal blocks |
| Isolation | 1500 V AC (channel-to-bus, typical) |
| Status Indicators | LED indicators for power, communication, and fault |
| WEEE Category | Product typically not in WEEE scope as a component |
Design for Reliability and Diagnostics
The ABB DSCS131 57310001-LM incorporates clear LED status indicators for power and communication. Moreover, its robust electrical isolation protects sensitive control signals from noise. This design philosophy prioritizes long-term operational stability and easy maintenance. For reliable power distribution within such systems, quality components like the RMS-TSG-TZ-C static trip unit are essential.
Application and Value Proposition
This module is ideal for expanding or modernizing existing ABB Harmony/Advant control systems. It provides a proven and reliable solution for essential plant communication tasks. Choosing the genuine ABB DSCS131 57310001-LM ensures full compatibility and supported performance. Furthermore, its standardized design simplifies both initial integration and future system upgrades.
Details
| Weight | 0.595 kg |
|---|---|
| Dimensions | 18 × 225 × 209.7 mm |
