Core Function and Application
The ABB DSCA160A serves as a dedicated RS-232 communication processor unit. Consequently, it manages efficient serial data transmission within complex automation networks. This module reliably integrates various devices into overarching ABB control systems. Therefore, it ensures stable and consistent data exchange in demanding industrial settings.
Design for Reliable Serial Communication
Specifically, the DSCA160A module facilitates robust point-to-point RS-232 communication. Furthermore, its design prioritizes signal integrity over typical industrial distances. This processor efficiently handles protocol conversion and data buffering tasks. Ultimately, it creates a seamless link between legacy serial devices and modern control systems.
Detailed Technical Specifications
The unit features a compact and robust design for easy integration into standard racks. Below is a comprehensive table of its key technical and physical parameters.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model Number | DSCA160A |
| Catalog Description | RS-232 Communication Processor |
| Product Type | Communication Interface Module |
| Primary Communication Interface | Standard RS-232 Serial Port |
| Customs Tariff Number | 8517620000 |
| Dimensions (H x W x D) | 2.5 cm x 25.4 cm x 25.4 cm |
| Weight | 0.6 kg |
| Connector Type | Industrial-grade terminal block or D-sub (model specific) |
| Operating Voltage | Typically 24 VDC (confirm with system specs) |
| Data Transfer Rate | Configurable, standard RS-232 baud rates up to 115.2 kbps |
| Isolation | Signal isolation for noise immunity (typical) |
| WEEE Category | Product not in WEEE scope |
| Compatible Series | Designed for integration with ABB Advant and Symphony series systems |
Integration and Compatibility
This processor unit seamlessly integrates with ABB’s Advant and Symphony series control platforms. Moreover, its standardized dimensions allow for straightforward installation in control cabinets. For robust connection solutions similar to industrial terminals, components like the RMS-TSG-TZ-C static trip unit highlight the importance of reliable interfaces.
Key Operational Benefits
The ABB DSCA160A provides a critical and reliable communication gateway. It effectively extends the lifecycle of essential serial-based field devices. This module also simplifies system architecture and reduces integration complexity. Choosing this genuine ABB component guarantees optimal performance and system harmony.
Details
| Weight | 0.595 kg |
|---|---|
| Dimensions | 18 × 225 × 209.7 mm |
