The ABB DSAO120A 3BSE018293R1 is an eight-channel analog output module for industrial automation. This robust board delivers precise command signals to a variety of field actuators and control devices. Consequently, it ensures accurate execution of your automated process control strategies.
Core Signal Output Capabilities and Integration
This high-performance module excels at converting digital commands into stable analog outputs. It supports both current and voltage signal types for maximum application flexibility. Moreover, the DSAO120A series provides essential channel isolation for superior signal integrity and safety.
The board integrates seamlessly into ABB’s industrial control system architecture. Therefore, it serves as a reliable interface between the controller and final control elements like valves.
Detailed Physical and Compliance Specifications
The 3BSE018293R1 variant features specific dimensions and regulatory information for global shipping and installation. Below are its comprehensive technical and physical specifications.
Comprehensive Technical Specifications:
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Series | DSAO120A Series |
| Ordering Number / Model | 3BSE018293R1 |
| Module Category | Analog Output Board (I/O Module) |
| Number of Channels | 8 Isolated Output Channels |
| Output Signal Types | 4-20 mA, 0-20 mA, 0-10V, ±10V |
| Typical Output Accuracy | ±0.05% of Full Scale (Model Specific) |
| Channel Isolation | Galvanic isolation between outputs |
| Product Dimensions (H x W x D) | 27 mm x 234 mm x 324 mm |
| Product Net Weight | 0.372 kg |
| Primary Component Count | 8 DACs, isolation circuitry, controller IC |
| Electrical Interface | High-density terminal connector |
| Power Supply | System backplane powered (+24V DC typical) |
| Harmonized System (HS) Code | 853890 |
| Customs Tariff Number | 85389091 |
| RoHS Compliance Status | Not RoHS Compliant |
| WEEE Category | 5 – Small Equipment |
| Internal Battery Count | 0 |
| SCIP Notification UUID | fc782cde-38bb-4056-a3f2-28a7277ecf1e |
| Typical Update Rate | <10 ms per channel (all channels) |
| Load Compatibility | Up to 500 Ω for current outputs |
Application and Global Sourcing Context
This module is essential for driving control elements in process industries such as chemicals and power. For sourcing specialized industrial automation spares, suppliers on platforms like Alibaba may list related items. For instance, you can find components like the RMS-TSG-TZ-C Static Trip unit for electrical protection systems.
Details
| Weight | 0.595 kg |
|---|---|
| Dimensions | 18 × 225 × 209.7 mm |
