The ABB D0910S is a reliable digital output module designed for industrial automation systems. This compact module provides secure switching for actuators, valves, and indicator lamps. It integrates seamlessly into modular I/O racks from ABB and compatible third-party systems.
Engineers utilize the D0910S for precise on/off control in sequential processes. The module ensures safe and dependable operation of connected field devices. Consequently, it serves as a fundamental component for machine control and plant automation.
Comprehensive Technical Specifications
The D0910S delivers robust performance with precise engineering specifications. The following table details its complete electrical, mechanical, and operational parameters.
| Parameter | Specification |
|---|---|
| Manufacturer & Model | ABB D0910S |
| Module Type | Digital Output, Sourcing (PNP) |
| Number of Channels | 8 Isolated Output Channels |
| Output Switching Type | Solid-State (MOSFET) |
| Output Voltage Range | 24 VDC (10.8-30 VDC) |
| Continuous Current per Channel | 0.5 A |
| Maximum Total Module Current | 4.0 A |
| Peak Current per Channel | 2.0 A (100 ms) |
| On-State Voltage Drop | ≤ 1.5 V @ 0.5 A |
| Off-State Leakage Current | ≤ 10 µA |
| Switching Frequency | Up to 100 Hz |
| Communication Interface | Backplane Parallel / System Dependent |
| Field Connection | Removable Screw Terminal Block |
| Module Dimensions (HxWxD) | 120 mm x 25 mm x 115 mm |
| Module Weight | 180 grams |
| Power Dissipation | Approx. 3 W (fully loaded) |
| Isolation Voltage | 500 Vrms (Channel-to-Backplane) |
| Internal Component Count | 8x Power MOSFETs, 8x Opto-isolators, 1x Driver IC |
| Protection Features | Short-Circuit, Overload, Over-temperature |
Design for Durability and Easy Maintenance
This module from ABB features robust solid-state outputs for long service life. Its comprehensive electronic protection safeguards against wiring faults and overloads. Moreover, the optical isolation prevents backplane damage from field-side electrical disturbances.
The compact form factor allows for high-density installations within control cabinets. Status LEDs for each channel provide immediate visual feedback on output state. Therefore, maintenance personnel can quickly troubleshoot system operations and field connections.
Key Application Areas
The D0910S is ideal for controlling a wide array of industrial devices. Common applications include solenoid valves, contactor coils, and small motor starters. It also reliably drives pilot lights, alarms, and other indicator devices on control panels.
This module supports essential functions in packaging, material handling, and assembly lines. Its fast switching capability is suitable for simple motion control and sequencing tasks. Ultimately, it provides the critical link between the control system and the physical process.
