Core Gateway Function for Distributed Control
The ABB CI830 3BSE013252R1 is a PROFIBUS DP communication interface module. This unit seamlessly connects ABB controllers to distributed PROFIBUS DP field device networks. It supports both DP-V0 and DP-V1 protocols for broad compatibility with various slaves. Consequently, it is essential for building flexible and scalable distributed control system architectures.
Robust Connectivity and Safety Features
This interface features a standard 9-pin D-subminiature connector for network attachment. It provides galvanic isolation between the controller and the fieldbus for enhanced electrical safety. The CI830 supports high-speed baud rates up to 12 Mbps for fast data exchange. Furthermore, its DIN-rail mounting design allows for quick and easy installation within control panels.
Detailed Technical Specifications
Engineered for industrial environments, the module operates reliably across a wide temperature range. It meets stringent EMC standards to ensure stable performance in electrically noisy plants. The following table details its complete electrical, environmental, and mechanical parameters.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Model | CI830 3BSE013252R1 |
| Module Type | PROFIBUS DP Communication Interface |
| Supported Protocols | PROFIBUS DP-V0, DP-V1 |
| Connector | 9-pin D-subminiature |
| Max Supported Slaves | Up to 3 |
| Max Baud Rate | Up to 12 Mbps |
| Key Safety Feature | Galvanic Isolation |
| Power Supply | 24 V DC |
| Power Consumption | 5 W |
| Operating Temperature | -20°C to +60°C |
| Storage Temperature | -40°C to +85°C |
| Humidity Range | 0 to 95% RH (non-condensing) |
| Vibration Resistance | 0.5 mm peak-to-peak (10-50 Hz) |
| Shock Resistance | 15 g for 44 ms |
| EMC Compliance | EN 61000-6-2, EN 61000-6-3 |
| Mounting | DIN Rail |
Primary Applications and Integration
Use this module to interface ABB controllers with other PROFIBUS DP devices like drives and I/O. It is ideal for applications in manufacturing, process automation, and material handling systems. The ABB CI830 3BSE013252R1 simplifies network integration and reduces wiring complexity. Therefore, it is a key component for achieving efficient and centralized control over distributed assets.
Details
| Weight | 8.5 kg |
|---|---|
| Dimensions | 280 × 458 × 87 mm |
