The IEPEP07 communication module from ABB Bailey links INFI 90 and Net 90 controllers with external networks and supervisory systems. Plant engineers select this module whenever they need reliable data exchange between distributed control nodes. Consequently, it plays a central role in plant-wide automation architectures.
Key Technical Specifications
The table below summarizes the main physical and electrical parameters of the IEPEP07 module.
| Parameter | Specification |
|---|---|
| Product Type | Communication Module |
| Compatibility | ABB Bailey INFI 90 / Net 90 systems |
| Dimensions | Approximately 178 mm × 102 mm × 25 mm |
| Weight | Approximately 0.25 kg (0.55 lbs) |
| Mounting | Standard INFI 90 module rack slot |
| Interface | Backplane bus and serial communication ports |
| Connectors | Multi-pin edge connector and D-sub ports |
| Component Count | Multiple integrated circuits and communication controllers |
| Energy Storage | On-board capacitors for signal and memory backup |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% non-condensing |
Functional Overview
This module manages protocol handling and message routing between controllers and higher-level systems. Therefore, it reduces the processing burden on the main control processor. The IEPEP07 supports serial links for configuration tools, operator stations, and data historians. Meanwhile, its onboard energy storage protects communication buffers during brief power dips.
Installation and Handling Notes
Always confirm firmware compatibility before inserting the IEPEP07 into an active rack. In addition, check that addressing switches match your network topology. Tighten the retaining screws evenly to avoid connector stress. Finally, document all port assignments for future troubleshooting.
Details
| Weight | 0.35 kg |
|---|---|
| Dimensions | 90 × 45 × 100 mm |
