Overview
The ABB 3BHL000986P0006 Capacitor Module delivers reliable energy storage for high-voltage industrial applications. Designed for efficiency and durability, it supports DIN rail mounting and ensures fast discharge for operational safety. The module features precision screw terminals, reinforced industrial-grade materials, and robust insulation properties.
Key Features
- High-performance 4 µF capacitance for stable energy storage
- Rated for 2800 VDC with a maximum of 4500 VDC, suitable for demanding environments
- Quick discharge time of under 2 seconds from full voltage to zero
- Supports DIN rail mounting for flexible installation in control panels
- Screw terminal connections simplify wiring and maintenance
- Resistant to ESD shocks up to 8 kV direct contact
- Operates reliably in humidity from 10% to 95% RH, non-condensing
- Vibration-tolerant design: 2 g peak, 10–500 Hz
Technical Specifications
| Specification | Details |
|---|---|
| Capacitance | 4 µF |
| Voltage Rating | 2800 VDC (4500 VDC max) |
| Operational Temperature | -20°C to +70°C |
| Dimensions | 150 mm × 100 mm × 50 mm |
| Weight | 1.2 kg |
| Mounting Type | DIN rail |
| Connection Type | Screw terminals |
| Material | Industrial-grade plastic with metal reinforcements |
| Insulation Resistance | >100 MΩ at 1000 VDC |
| Leakage Current | <1 mA at 2800 VDC |
| Discharge Time | <2 seconds from 2800 VDC to 0 V |
| ESD Protection | Up to 8 kV direct contact |
| Humidity Tolerance | 10% to 95% RH (non-condensing) |
| Vibration Resistance | 2 g peak, 10–500 Hz |
Dimensions & Weight
- Dimensions: 150 mm × 100 mm × 50 mm
- Weight: 1.2 kg
- Mounting: DIN rail compatible
Origin
- Manufactured in: Germany (ABB)
Details
| Weight | 1.2 kg |
|---|---|
| Dimensions | 150 × 100 × 50 mm |
