Overview
The ABB 3BHE028761R1001 Gate Driver integrates the GD C806A and HA C807A modules into a compact and reliable design for medium-voltage drive systems. I value its strong electrical isolation because it protects sensitive control circuits during switching events. Additionally, it supports stable gate signal delivery, which ensures accurate IGBT operation across demanding industrial environments.
Electrical Performance
The GD C806A and HA C807A modules work together to deliver precise gate pulses, and this accuracy strengthens high-power converter reliability. Their 24 V DC supply input simplifies installation because most ABB drive cabinets follow the same voltage standard. Furthermore, the 5 A output capability supports fast IGBT switching cycles, which improves system efficiency.
Interface & Signal Control
I highlight the 5 V DC input signal requirement since many modern PLCs and controller boards use this reference level. The card also includes reinforced isolation rated at 2500 V DC, and this protection reduces the risk of damage from transient spikes or back-EMF during heavy switching operations. Moreover, the board layout ensures clean signal separation, which benefits applications requiring noise immunity.
Mechanical Properties
The 3BHE028761R1001 Gate Driver uses a durable and lightweight structure that fits easily into ABB ACS-series drive cabinets. Its 0.25 kg weight supports flexible mounting, while its stable construction resists mechanical vibration. Because ABB designed the module for harsh operating zones, it maintains consistent performance between −40°C and +85°C.
Application Range
The GD C806A and HA C807A modules operate effectively inside the ABB ACS2000 drive platform. Engineers often choose the module because it supports fast switching, strong isolation, and dependable gate control. It also provides predictable performance in energy plants, heavy-duty motors, and power-conversion systems where stable gate triggering determines system reliability.
Technical Specifications
| Specification | Value |
|---|---|
| Manufacturer | ABB |
| Product ID | 3BHE028761R1001 |
| Models Included | GD C806A, HA C807A |
| Type | Gate Driver |
| Power Supply | 24 V DC |
| Max Output Current | 5 A |
| Input Signal Voltage | 5 V DC |
| Isolation Voltage | 2500 V DC |
| Operating Temperature | −40°C to +85°C |
| Net Weight | 0.25 kg |
| Customs Tariff Code | 85049099 |
| Minimum Order Quantity | 1 piece |
| Country of Origin | Switzerland |
Dimensions & Weight
- Net Weight: 0.25 kg
- Dimensions: Manufacturer does not publish physical dimensions; typical driver modules fit standard ABB ACS2000 drive slots.
Country of Origin
- Origin: Switzerland
Details
| Weight | 0.25 kg |
|---|---|
| Dimensions | 130 × 180 × 55 mm |
