Product Overview
The Honeywell 8C-PAOHA1 is a high-level analog output module designed to deliver precise 4-20 mA signals to HART-enabled actuators and recording devices.
Moreover, it supports redundancy configurations and per-channel fail-safe (FAILOPT) behavior, ensuring continuous operation during system faults. This module is suitable for critical industrial applications requiring reliable, precise output control.
Functional Highlights
- Fail-Safe Configurability: Each channel can HOLD LAST VALUE or SHED to SAFE VALUE, defaulting to zero on failure.
- Open-Wire Detection: Alerts users of open field wiring via channel soft failure notifications.
- Redundancy Support: Optional redundant configuration increases system reliability and minimizes downtime.
- HART Protocol: Fully compatible with multivariable HART communication for intelligent field devices.
In addition, the module ensures rapid response time of 80 ms and a redundancy switchover gap of 10 ms, maintaining operational stability.
Technical Data
| Parameter | Specification |
|---|---|
| Model | 8C-PAOHA1 |
| Output Channels | 16 |
| Output Type | 4-20 mA |
| Voltage Rating | 24 VDC |
| Current Rating | 205 mA |
| Load Resistance | 50–800 Ω |
| Output Ripple | <100 mV p-p across 250 Ω |
| Resolution | ±0.05% of full scale |
| Accuracy | ±0.2% full scale at 25°C |
| Output Range | 2.9–21.1 mA |
| Response Time | Settles within 1% of final value in 80 ms |
| Maximum Open Circuit Voltage | 22 V |
| Certifications | Class I Div 2 Groups A–D, Zone 2 Ex nA II C T4 |
These specifications make the 8C-PAOHA1 module ideal for precise and reliable analog output performance in HART-enabled industrial networks.
Details
| Weight | 1.8 kg |
|---|
