The ABB AI561 (1TNE968902R1101) is an analog input module from the S500-eCo I/O series. It provides four analog inputs for voltage and current signals, making it a reliable choice for distributed automation systems.
Key Features
- 4 analog inputs (U, I) for versatile signal acquisition.
- 12-bit resolution ensures precise measurement.
- Pluggable connection type for easy installation.
- Compact design with DIN rail compatibility.
- Housing protection rating IP20 for safe operation.
Technical Specifications
- Product Type: AI561 Analog Input Module
- Product ID: 1TNE968902R1101
- Number of Analog Inputs: 4
- Input Signal: Voltage (U), Current (I)
- Resolution: 12-bit
- Operating Temperature: 0 … +60 °C
- Storage Temperature: -40 … +70 °C
- Degree of Protection: IP20
Dimensions and Weight
- Net Weight: 0.12 kg
- Dimensions (L × H × W): 135 × 74 × 34 mm
- Gross Weight: 0.16 kg
Compliance and Standards
- eClass: 27-24-22-02
- ETIM 8: EC001420 – PLC analogue I/O module
- UNSPSC: 32151705
- WEEE Category: 5. Small Equipment
Applications
The AI561 module is designed for PLC automation systems within the ABB AC500-eCo platform. It is suitable for industrial processes requiring reliable and accurate analog signal monitoring.
Details
| Weight | 0.12 kg |
|---|---|
| Dimensions | 135 × 34 × 74 mm |
