Overview
The 129486-01 High Voltage DC Power Supply Module provides reliable DC power for Bently Nevada 3500 Series monitoring systems. Its robust design supports full-rack operation with options for redundancy, ensuring uninterrupted performance in critical industrial applications.
Key Features
- High-voltage DC input: 88–140 VDC
- Maximum full-rack current draw: 2.5 A
- Supports redundant operation with dual half-height slots
- Designed for Bently Nevada 3500 Series racks
- Industrial-grade reliability with wide operating temperature range
Technical Specifications
| Feature | Specification |
|---|---|
| Part Number | 129486-01 |
| Module Type | High Voltage DC Power Supply |
| Input Voltage | 88–140 VDC |
| Full Rack Current Draw | 2.5 A maximum |
| Rack Space Requirements | 2 half-height slots (left side of rack) |
| Dimensions (H x W x D) | 120.7 × 50.8 × 251.5 mm (4.75 × 2.0 × 9.9 in) |
| Weight | 1.39 kg (3.06 lbs) |
| Operating Temperature | -30 °C to +65 °C (-22 °F to +150 °F) |
| Storage Temperature | -40 °C to +85 °C (-40 °F to +185 °F) |
| Humidity | Up to 95%, non-condensing |
Details
| Weight | 1.39 kg |
|---|
